[gpfsug-discuss] Serial number of [EG]SS nodes

[Steven Daniels]

If xcat is on gss, then you can run nodels and use the node name for lsdef
-t node <node name from nodels) to get the serial number

on E3K, tsplatformstat -C

On power (non-hmc based)  nodes in general
ipmitool fru print 0

Steven A. Daniels
Cross-brand Client Architect
Senior Certified IT Specialist
National Programs
Fax and Voice: 3038101229
sadaniel at us.ibm.com
http://www.ibm.com
(See attached file: opencits-d.jpg)



From:	"Simon Thompson" <S.J.Thompson at bham.ac.uk>
To:	"gpfsug main discussion list"
            <gpfsug-discuss at spectrumscale.org>
Date:	09/02/2021 09:53 AM
Subject:	[EXTERNAL] Re: [gpfsug-discuss] Serial number of [EG]SS nodes
Sent by:	gpfsug-discuss-bounces at spectrumscale.org



Depends if it was filled in at install time, but mmlscomp might hold the
data (on both ESS and DSS systems)…

I guess that is where the GUI reads the data from also?

Simon

From: <gpfsug-discuss-bounces at spectrumscale.org> on behalf of
"abeattie at au1.ibm.com" <abeattie at au1.ibm.com>
Reply to: "gpfsug-discuss at spectrumscale.org"
<gpfsug-discuss at spectrumscale.org>
Date: Thursday, 2 September 2021 at 16:51
To: "gpfsug-discuss at spectrumscale.org" <gpfsug-discuss at spectrumscale.org>
Subject: Re: [gpfsug-discuss] Serial number of [EG]SS nodes



I’m not sure for the Lenovo

But the GUI hardware details tabs has MTM and serial information for all
the ESS nodes.


Regards

Andrew

> On 3 Sep 2021, at 01:39, Hannappel, Juergen <juergen.hannappel at desy.de>
wrote:
>
> Hi,
> on an ESS node with power cpu I can get the serial number from
> /proc/device-tree/system-id
> which is very useful sometimes
> On nodes with X86 architecture (Lenovo GSS or IBM ESS3XXX_) there
> is no such pseudo-file. Is there a simple way to get at the serial
number?
> --
> Dr. Jürgen Hannappel  DESY/IT    Tel.  : +49 40 8998-4616
